Technical parameters:

- Bandwidth: 7-54MHz (By properly adjusting the length of the vibrator, it can work in the UV segment)

- SWR: <1.5

- Polarization mode: Horizontal polarization

- Input impedance: 50 Ω

- Continuous withstand power: 200W

- Maximum withstand power: 500W

- Folded size: 0.52m/1.7ft

- Maximum stretched size: 11.3m/37.1ft

- Maximum windward face: 0.026m2
