Product Description
MODEL NO.: AT-D878UVII PLUS
Functions:
#True-2-slot: Provide 2-slot communication which allows for 2 talk paths on 1 frequency; ETSI DMR Tier I and II compliant
#Power:VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W #Auto-senses digital or analog reception
#4000 channels + VFO; 10,000 talk groups with 200,000 digital contacts
#Display: 1.77 inch TFT color LCD, dual display; dual standby; dual PA
#Bandwidth: 12.5K/25K (Analog); 12.5K (DMR) #Fixed and defined CTCSS/DCS encode and decode #DTMF/2TONE/5TONE encode and decode
#Four different Tone-pluse frequencies #Individual/Group/All call
#Support Contact Manager
#Display the Caller ID and name
#SMS via keyboard, One touch call/text
#Zone selection; Ranging function between radios with GPS
#ANI function and PTT ID; VOX; Digital Recording and Play
#Roaming function; Talker alias function #IP connect to Motorola Repeater
#Emergency alarm (with GPS data transmission)
#Either Voice Recording 500 hours(optional) or BT (optional)
#GPS with APRS location reporting(optional)
#AES256 Digital encrytion
#Earphone: KENWOOD connector; Waterproof: IP54
#Battery: 3100mAh Li-ion thick battery 2100mAh Polymer filmy battery(optional)
#Power:VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W #Auto-senses digital or analog reception
#4000 channels + VFO; 10,000 talk groups with 200,000 digital contacts
#Display: 1.77 inch TFT color LCD, dual display; dual standby; dual PA
#Bandwidth: 12.5K/25K (Analog); 12.5K (DMR) #Fixed and defined CTCSS/DCS encode and decode #DTMF/2TONE/5TONE encode and decode
#Four different Tone-pluse frequencies #Individual/Group/All call
#Support Contact Manager
#Display the Caller ID and name
#SMS via keyboard, One touch call/text
#Zone selection; Ranging function between radios with GPS
#ANI function and PTT ID; VOX; Digital Recording and Play
#Roaming function; Talker alias function #IP connect to Motorola Repeater
#Emergency alarm (with GPS data transmission)
#Either Voice Recording 500 hours(optional) or BT (optional)
#GPS with APRS location reporting(optional)
#AES256 Digital encrytion
#Earphone: KENWOOD connector; Waterproof: IP54
#Battery: 3100mAh Li-ion thick battery 2100mAh Polymer filmy battery(optional)
Specification
General | ||
Frequency Range | Europe: 144-146MHz(V),430-440MHz(U) United State: 136-174MHz(V),400-480MHz(U) Australia: 144-148MHz(V), 420-450MHz(U) India:144-146MHz(V), 436-438MHz(U) | |
Channel Capacity | 4000 channels | |
Channel Spacing | 25KHz (Wide Band) ,12.5KHz (Narrow Band) | |
Phase-locked Step | 5KHz, 6.25KHz | |
Operating Voltage | 7.4V DC ±20% /(2100mAh/3100mAh) | |
Frequency Stability | ±2.5ppm | |
Operating Temperature | -20℃~ +55℃ | |
Size | 129×61×39mm (with battery pack) | |
Weight | 282g (with battery pack, antenna) | |
Receiving Part | ||
Wide band | Narrow band | |
Sensitivity(12dB SINAD) | ≤0.25μV | ≤0.35μV |
Digital Sensitivity | 0.3uV/-117.4dBm (BER 5%) 0.7uV/-110dBm (BER 1%) | |
Adjacent Channel Selectivity | ≥70dB | ≥60dB |
Spurious Emission | ≤-57dB | ≤-57dB |
Spurious Rejection | ≥70dB | ≥70dB |
Blocking | 84db | |
Hum & Noise | ≥45dB | ≥40dB |
Audio Distortion | ≤5% | |
Audio Power Output | 1000mW/16Ω | |
Transmitting Part | ||
Wide band | Narrow band | |
Power Output | VHF: 7/5/2.5/1W, UHF: 6/5/2.5/1W | |
Modulation | ±5.0KHz@25KHz | ±2.5KHz@12.5KHz |
Adjacent Channel Power | ≥70dB | ≥60dB |
Hum & Noise | ≥40dB | ≥36dB |
Spurious Emission | ≤-36dBm | ≤-36dBm |
4FSK Digital Modulation | 12.5KHz（data）7K60FXD 12.5KHz（data+voice）7K60FXE | |
Audio Distortion | ≤5% | |
Error rate | ≤3% | |
ANYTONE AT-D878UV II PLUS
- Brand: ANYTONE
- Product Code: AT-D878UV II PLUS
- Availability: 1
-
RM900.00
- Ex Tax: RM900.00
